7Q-26.000MBS-T,7Q系列晶振,3.3V晶体,TXC晶技振荡器，物料编码7Q-26.000MBS-T，型号为7Q系列晶振，电压为3.3V晶体，频率为26MHz，精度为±2ppm，工作温度范围为-30-85℃，尺寸为3.2*2.5mm，输出Clipped Sine Wave晶振，四脚晶振，VC-TCXO晶振,有源晶体，TXC晶技振荡器，石英晶体振荡器，3225晶振，晶振厂家，特点：低相噪，低抖动，低电压，被广泛应用在智能电脑，智能平板，海上军舰，游轮，潜艇等。
7Q-26.000MBS-T,7Q系列晶振,3.3V晶体,TXC晶技振荡器
| 规格参数表 | |
| 型号 | 7Q |
| 频率 | 26MHz |
| 精度 | ±2ppm |
| 工作温度范围 | -30℃-85℃ |
| 电压 | 3.3V |
| 输出 | Clipped Sine Wave |
7Q-26.000MBS-T,7Q系列晶振,3.3V晶体,TXC晶技振荡器
| 物料编码 | 描述 | 系列 | 频率 | 输出 | 电压 | 精度 | 工作温度 |
| 7Q-16.367667MBN-T | 晶振厂家 | 7Q | 16.367667 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.368MBN-T | XTAL OSC TCXO 16.3680MHZ SNWV | 7Q | 16.368 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
| 7Q-19.200MBS-T | XTAL OSC VCTCXO 19.2000MHZ SNWV | 7Q | 19.2 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
| 7Q-26.000MBS-T | XTAL OSC VCTCXO 26.0000MHZ SNWV | 7Q | 26 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
| 7Q-40.000MBS-T | XTAL OSC VCTCXO 40.0000MHZ SNWV | 7Q | 40 MHz | Clipped Sine Wave | 3.3V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.367667MBG-T | XTAL OSC TCXO 16.367667MHZ SNWV | 7Q | 16.367667 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.3676MBG-T | XTAL OSC TCXO 16.3676MHZ SNWV | 7Q | 16.3676 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.368MBG-T | XTAL OSC TCXO 16.3680MHZ SNWV | 7Q | 16.368 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.369MBG-T | XTAL OSC TCXO 16.3690MHZ SNWV | 7Q | 16.369 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
| 7Q-26.000MBG-T | XTAL OSC TCXO 26.0000MHZ SNWV | 7Q | 26 MHz | Clipped Sine Wave | 3.3V | ±500ppb | -30°C ~ 85°C |
| 7Q-12.800MCS-T | XTAL OSC VCTCXO 12.8000MHZ SNWV | 7Q | 12.8 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.000MCS-T | XTAL OSC VCTCXO 16.0000MHZ SNWV | 7Q | 16 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.3676MCS-T | XTAL OSC VCTCXO 16.3676MHZ SNWV | 7Q | 16.3676 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.367667MCS-T | XTAL OSC VCTCXO 16.367667MHZ SNW | 7Q | 16.367667 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.368MCS-T | XTAL OSC VCTCXO 16.3680MHZ SNWV | 7Q | 16.368 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-16.369MCS-T | XTAL OSC VCTCXO 16.3690MHZ SNWV | 7Q | 16.369 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-19.200MCS-T | XTAL OSC VCTCXO 19.2000MHZ SNWV | 7Q | 19.2 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-20.000MCS-T | XTAL OSC VCTCXO 20.0000MHZ SNWV | 7Q | 20 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-20.800MCS-T | XTAL OSC VCTCXO 20.8000MHZ SNWV | 7Q | 20.8 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-24.000MCS-T | XTAL OSC VCTCXO 24.0000MHZ SNWV | 7Q | 24 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-26.000MCS-T | XTAL OSC VCTCXO 26.0000MHZ SNWV | 7Q | 26 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-27.000MCS-T | XTAL OSC VCTCXO 27.0000MHZ SNWV | 7Q | 27 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-38.400MCS-T | XTAL OSC VCTCXO 38.4000MHZ SNWV | 7Q | 38.4 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-40.000MCS-T | XTAL OSC VCTCXO 40.0000MHZ SNWV | 7Q | 40 MHz | Clipped Sine Wave | 2.5V | ±2ppm | -30°C ~ 85°C |
| 7Q-12.800MCG-T | XTAL OSC TCXO 12.8000MHZ SNWV | 7Q | 12.8 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.000MCG-T | XTAL OSC TCXO 16.0000MHZ SNWV | 7Q | 16 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.3676MCG-T | XTAL OSC TCXO 16.3676MHZ SNWV | 7Q | 16.3676 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
| 7Q-16.367667MCG-T | XTAL OSC TCXO 16.367667MHZ SNWV | 7Q | 16.367667 MHz | Clipped Sine Wave | 2.5V | ±500ppb | -30°C ~ 85°C |
